Tehnilised andmed
Dimensions 115 x 192 x 43.7 mm
Weight 650 g
Networking interface (2) 10/100 MbE RJ45 ports
Management interface Ethernet In-Band
Power method AC input: 100-240V AC, 50-60 Hz, universal input
Battery input: DC terminal block
Power supply AC input: AC/DC 72W
Battery input: 12V DC lead acid battery*
*Battery not included. Connect to a lead-acid battery only. Using another battery type could be hazardous.
Max. power consumption System: 2W
Output: 72W
PoE output (2) 54V DC passive PoE (Pins 4, 5+; 7, 8-)
DC output 54V, 1.3A
LEDs System: status
RJ45 data ports: PoE; link/activity
ESD/EMP protection Air: ± 12kV, contact: ± 12kV
Ambient operating temperature 0 to 40° C
Ambient operating humidity 10 to 90% noncondensing
Certifications CE, FCC, IC
